1x2 4K HDMI Extender Splitter Over Single CAT6/7 Up to 230 Ft - ipcolor Technology 18 Gbps, RS-232, EDID (UHD12-IPC230-K)
- Supports ipcolor technology
- Supports 18Gbps video bandwidth
- Supports RS-232 Control & Advance EDID
*Overnight shipping doesn't include Weekends, or any holidays.
OREI UHD12-IPC230-K 4K HDMI Extender Splitter up to 230Ft
- Compliant with HDMI 2.0 and HDCP 2.2 – Ensures compatibility with modern HDMI sources and encrypted content for seamless AV performance.
- Supports Audio Formats – Compatible with LPCM, DTS-HD, DTS-Audio, and Dolby Digital 5.1 for immersive and high-fidelity sound.
- Zero-Latency Transmission – Delivers real-time AV performance, making it ideal for interactive or live monitoring applications.
-
1 HDMI Input to 2 Network Outputs – Simultaneously split and extend a single HDMI input signal to two IP-based outputs for parallel display.
- 4K@60Hz Resolution Support – Handles ultra-high-definition video with stunning clarity and color accuracy.
-
Long-Distance Extension up to 70 Meters – Transmits HDMI signals over Cat6/6A/7 cables up to 230 feet with no compromise in quality.
- Bi-Directional IR Passback Support – Enables remote control of source or display devices from either end.
- HDMI Loop-Out on Transmitter – Allows for local display connection without interrupting signal extension to remote receivers.
- Digital Audio Extraction via S/PDIF – Receiver supports optical audio output, allowing separate audio routing for sound systems.
- EDID Passthrough and Manual Configuration – Automatically reads connected display EDID or allows manual EDID setting for optimized compatibility.
- RS-232 Command Control – Provides integration with third-party automation and control systems.
-
Enhanced Protection Design – Built-in surge, lightning, and ESD protection ensures reliable operation in demanding environments.
- Rack-Mountable – Includes rack ears for easy installation in professional AV cabinets or equipment racks.
The UHD12-IPC230-K is a 1x2 HDMI Extender Splitter Kit that combines signal distribution and long-distance extension in one compact unit. It splits one HDMI source into two synchronized network outputs and extends them up to 70 meters over Cat6 or higher Ethernet cables, supporting 4K@60Hz resolution with zero latency.
Ideal for applications such as broadcast studios, classrooms, transportation hubs, or digital signage networks, this kit includes advanced features like HDMI loop-out, bi-directional IR passback, and optical S/PDIF audio output from the receiver. For complete control, it offers RS-232 connectivity and EDID management options.
With rack-mountable design and robust electrical protection, the UHD-IPSP2-K is engineered for professional AV environments that demand reliability, scalability, and exceptional performance.
UHD12-IPC230-K User Manual Download
