MATRIX Matrix with video wall

2 Products
  • Transmitter:
    • Input Ports:
      • 8x HDMI Female
    • Output Ports:
      • 8x HDMI Male
  • Receiver:
    • Input Ports:
      • 8x HDMI Female
    • Output Ports:
      • 8x HDMI Male
  • HDMI Compliance: HDMI 2.0
  • HDCP Compliance: HDCP 2.2
  • DVI compliant
  • Video Resolutions: Up to 4K60 4:4:4
  • Color Space: RGB, YCbCr 4:4:4, YCbCr 4:2:2
  • HDMI Amplitude: T.M.D.S +/- 0.4Vpp
  • Differential Impedance: 100±15ohm
  • Baud rate and Protocol:
    • Baud rate: 9600, data bit: 8
    • Stop bit: 1, no parity checking
  • Ethernet: IE10.0+,HTML5
  • Operation Temperature: 32 - 104°F / 0 - 40°C
  • Storage temperature: -4°F - 158°F / -20°C ~ 70°C
  • ESD Protection - Human body model: ±8kV (air-gap discharge) & ±4kV (contact discharge)
  • Relative Humidity: 10 - 50% RH (no condensing)
  • Video Bandwidth: 18Gbps
  • Dimensions: 430(L) X 300(W) X 44 (H)
  • Weight: 5Kg
  • Power Supply - AC 110 - 240V
  • Power Consumption(Max): 100W
  • Housing: Metal
  • Color: Black
  • Transmitter:
    • Input Ports:
      • 4x HDMI Female
    • Output Ports:
      • 4x HDMI Male
  • Receiver:
    • Input Ports:
      • 4x HDMI Female
    • Output Ports:
      • 4x HDMI Male
  • HDMI Compliance: HDMI 2.0
  • HDCP Compliance: HDCP 2.2
  • DVI compliant
  • Video Resolutions: Up to 4K60 4:4:4
  • Color Space: RGB, YCbCr 4:4:4, YCbCr 4:2:2
  • HDMI Amplitude: T.M.D.S +/- 0.4Vpp
  • Differential Impedance: 100±15ohm
  • Baud rate and Protocol:
    • Baud rate: 9600, data bit: 8
    • Stop bit: 1, no parity checking
  • Ethernet: IE10.0+,HTML5
  • Operation Temperature: 32 - 104°F / 0 - 40°C
  • Storage temperature: -4°F - 158°F / -20°C ~ 70°C
  • ESD Protection - Human body model: ±8kV (air-gap discharge) & ±4kV (contact discharge)
  • Relative Humidity: 10 - 50% RH (no condensing)
  • Video Bandwidth: 18Gbps
  • Dimensions: 430mm(W) × 220mm(D) × 44mm(H)
  • Weight: 5Kg
  • Power Supply - AC 110 - 240V
  • Power Consumption(Max): 60W
  • Housing: Metal
  • Color: Black
