HDBASET Hdbaset hdmi extender

6 Products
  • Transmitter:
    • Input Ports:
      • 1x HDMI Type A [19-pin female]
      • 1x IR INPUT [3.5mm Stereo Mini-jack]
      • 1x RS232 [Phoenix jack]
    • Output Ports:
      • 1x HD BaseT Out [RJ45]
      • 1x HDMI Type A [19-pin female]
      • 1x IR OUTPUT [3.5mm Stereo Mini-jack]
  • Receiver:
    • Input Ports:
      • 1x HD BaseT In [RJ45]
      • 1x IR INPUT [3.5mm Stereo Mini-jack]
      • 1x RS232 [Phoenix jack]
    • Output Ports:
      • 1x HDMI Type A [19-pin female]
      • 1x IR OUTPUT [3.5mm Stereo Mini-jack]
  • HDMI Compliance: HDMI 1.4
  • HDCP Compliance: HDCP 1.4
  • DVI compliant
  • Video Resolutions: Up to1080P @60Hz YUV4:4:4、RGB4:4:4
  • HDMI High Bit Rate(HBR) audio pass through
  • 150 meters transmission distance over CAT6 cable
  • POC (Power over Cable), either TX or RX is powered by one 24V@1A power supply
  • Bi-directional infrared control signal transmission
  • Bi-directional RS-232 signal transmission
  • HDMI Audio Formats (Pass-through): LPCM 2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby Digital+, Dolby True HD, DTS-HD Master Audio, Dolby Atmos, DTS:X
  • Color Space: RGB, YUV4:4:4, YUV 4:2:2
  • Color Depth: 8-bit
  • Operation Temperature: 32 - 104°F / 0 - 40°C
  • Storage temperature: -4 - 140°F / -20 - 60°C
  • ESD Protection - Human body model: ±8kV (air-gap discharge) & ±4kV (contact discharge)
  • Relative Humidity: 20 - 90% RH (no condensation)
  • Video Bandwidth: 225MHz
  • Dimensions: 140mm [W] x 65mm [D] x 18mm [H]
  • Weight: 481g
  • Power Supply - Input: AC100 - 240V 50/60Hz, Output: DC 24V/1A (US/EU standards, CE/FCC/UL certified)
  • Power Consumption: 6W
  • Housing: Metal
  • Color: Black
  • HDMI ULTRA HD EXTENDER: Extend the Signal Upto 130 Feet for 4Kat60hz with Cat5e/6 UTP cable. Extend 1080P signal upto 230 Feet (70 meters). Full Support 1080P 3D.
  • FULL 60HZ 4K Support: Supports 60Hzat4K, 1080P, 1080P 3D, 1080I, 720P, 576P, 576i, 480P. Supports All Audio: LCPSM, DTS HD and Dolby TrueHD.
  • Dual IR 20 - 60 kHz backward and forward extension. Poe (power over cable) function is supported. RS232 port for control signal transmission.
  • Orei HDBaseT is the most advanced chipset available. It has the most ESD protection and has passed numerous hours of testing under different
  • Full Orei lifetime support - 1 year warranty. Package includes: 1x HDMI receiver, 1x HDMI transmitter, 1x power adapter, 2x wideband IR TX, 2 x wideband IR RX
  • Transmitter:
    • Input Port:
      • 1x HDMI Type A [19-pin female]
    • Output Ports:
      • 1x HDMI Type A [19-pin female]
      • 1x HDBT OUT [RJ45, 8-pin female]
    • Control Ports:
      • 1x IR IN [3.5mm Stereo Mini-jack]
      • 1x IR OUT [3.5mm Stereo Mini-jack]
      • 1x RS-232 [Phoenix jack]
      • 1x SERVICE [Mini-USB, Update port]
  • Receiver:
    • Input Ports:
      • 1x HDBT IN [RJ45, 8-pin female]
    • Output Port:
      • 1x HDMI Type A [19-pin female]
      • 1x AUDIO OUT [3.5mm Stereo Mini-jack]
    • Control Ports:
      • 1x IR IN [3.5mm Stereo Mini-jack]
      • 1x IR OUT [3.5mm Stereo Mini-jack]
      • 1x RS-232 [Phoenix jack]
      • 1x SERVICE [Mini-USB, Update port]
  • HDMI Compliance: HDMI 2.0
  • HDCP Compliance: HDCP 1.4/2.2
  • Video Resolutions: Up to 4K@50/60Hz 4:4:4, 4K2K 50/60Hz 4:2:2, 4K2K 50/60Hz 4:2:0, 4K2K 30Hz 4:4:4, 1080p, 1080i, 720p, 720i, 480p, 480i. All HDMI 3D TV formats
  • POC (Power over Cable), either TX or RX is powered by one 24V@1A power supply
  • HDMI Audio Formats (Pass-through): LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, Dolby Digital Plus(DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X
  • L/R Audio Formats: PCM 2.0
  • Color Space: RGB / YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
  • Color Depth:
    • 8/10/12-bit (1080P60Hz, 4K30Hz, 4K60Hz YCbCr 4:2:2/4:2:0)
    • 8-bit (4K60Hz 4:4:4 )
  • Operation Temperature: 32°F ~ 104°F / 0°C ~ 40°C
  • Storage temperature: -4°F ~ 140°F / -20°C ~ 60°C
  • ESD Protection - Human body model: ±8kV (air-gap discharge) & ±4kV (contact discharge)
  • Relative Humidity: 20 - 90% RH (no condensation)
  • Video Bandwidth: 18Gbps
  • Dimensions: 140mm [W] x 65mm [D] x 18mm [H]
  • Weight:
    • Transmitter: 160g
    • Receiver: 155g
  • Power Supply:
    • Input: AC100 - 240V 50/60Hz
    • Output: DC 24V/1A (Locking connector)
  • Power Consumption: 9.36W
  • Housing: Metal
  • Color: Black
    • Extend Full HD Upto 4K x 2K @ 60Hz Signal upto 330 Feet VIA CAT5e/CAT6/CAT 7 Cable - With RS-232 And Power Over Cable
    • RS-232 serial signals and IR remote control signals (@ 39 KHz) also pass through the transceiver, so your HDBaseT installation can control such RS-232 devices as scanners and touchscreen displays at baud rates up to 115 Kbps.
    • Uncompressed - Support full HD 1080p,3D, 4Kx2K; HDMI1.4, Compatible with HDCP 2.0; Support CEC and 24bits deep color
    • Plug & Play Setup without any Software Installation. The extender is equipped with bi-directional IR pass-through which allows for source or display control.
    • Support: HDMI 480i 60HZ, 480p 60HZ, 576i 60HZ, 576 50HZ, 720p 50/60HZ, 1080i 50/60HZ, 1080P 50/60HZ, 20~50Khz IR Devices Supported
  • Transmitter:
    • Input Port:
      • 1x HDMI (IN) Type A [19-pin female]
    • Output Ports:
      • 1×HDBT [RJ45]
      • 1×L/R Stereo (OUT) [3.5mm Stereo Mini-jack]
      • 1×SPDIF (OUT) [S/PDIF]
    • Control Ports:
      • 1×IR IN [3.5mm Stereo Mini-jack]
      • 1×IR OUT [3.5mm Stereo Mini-jack]
      • 1×RS-232 (OUT) [Phoenix jack]
      • 1×Service [Micro-USB jack]
  • Receiver:
    • Input Ports:
      • 1×HDBT [RJ45]
      • 1×SPDIF (IN) [S/PDIF]
    • Output Port:
      • 1×HDMI (OUT) TypeA [19-pin female]
    • Control Ports:
      • 1×IR IN [3.5mm Stereo Mini-jack]
      • 1×IR OUT [3.5mm Stereo Mini-jack]
      • 1×RS-232 (OUT) [Phoenix jack]
      • 1×Service [Micro-USB jack]
  • HDMI Compliance: HDMI 2.0
  • HDCP Compliance: HDCP 2.2
  • DVI compliant
  • Video Resolutions: Up to 4K @60Hz YUV 4:4:4
  • The transmitter supports ARC function and local audio extract
  • Color Space: RGB, YCbCr4:4:4, YCbCr4:2:2, YCbCr 4:2:0
  • Color Depth:
    • 8-bit, 10-bit, 12-bit [1080P, 4K30Hz, 4K60Hz (YCbCr 4:2:0)]
    • 8-bit [4K60Hz (YCbCr4:4:4)]
  • Operation Temperature: 32°F ~ 104°F / 0°C ~ 40°C
  • Storage temperature: -4°F ~ 140°F / -20°C ~ 60°C
  • ESD Protection - Human body model: ±8kV (air-gap discharge) & ±4kV (contact discharge)
  • Relative Humidity: 20 - 90% RH (no condensation)
  • Video Bandwidth: 18Gbps
  • Dimensions: 165mm [W] x 88.3mm [D] x 20mm [H]
  • Weight:
    • Transmitter: 170g
    • Receiver: 165g
  • Power Supply - Input: AC100 - 240V 50/60Hz, Output: DC 24V/1A
  • Power Consumption: 13W (max)
  • Housing: Metal
  • Color: Black
  • Transmitter:
    • Input Ports:
      • 1x HDMI Type A [19-pin female]
    • Output Ports:
      • 1x HDBT OUT [RJ45, 8-pin female]
      • 1x SPDIF OUT [S/PDIF]
      • 1×L/R OUT [3.5mm Stereo Mini-jack]
      • 1×LAN [RG45]
    • Control Ports:
      • 1x IR IN [3.5mm Stereo Mini-jack]
      • 1x IR OUT [3.5mm Stereo Mini-jack]
      • 1x RS-232 [Phoenix jack]
      • 1x SERVICE [Mini-USB, Update port]
      • 1×USB HOST [USB Type B ]
  • Receiver:
    • Input Ports:
      • 1x HDBT IN [RJ45, 8-pin female]
      • 1x SPDIF IN [S/PDIF]
    • Output Ports:
      • 1x HDMI Type A [19-pin female]
      • 1x LAN [RG45]
    • Control Ports:
      • 1x IR IN [3.5mm Stereo Mini-jack]
      • 1x IR OUT [3.5mm Stereo Mini-jack]
      • 1x RS-232 [Phoenix jack]
      • 1x SERVICE [Mini-USB, Update port]
      • 2×USB 2.0 [USB Type A]
    • HDCP Compliance: HDCP 1.4/2.2
    • Support DVI compliant
    • Video Resolutions: Up to 4k2k@60Hz YUV 4:4:4
    • HDMI Audio: LPCM 2.0/2.1/5.1/6.1/7.1, Dolby Digital, Dolby TrueHD, Dolby Digital Plus(DD+), DTS-ES, DTS HD Master, DTS HD-HRA, DTS-X
    • Color Space: RGB / YCbCr 4:4:4, YCbCr 4:2:2, YCbCr 4:2:0
    • Color Depth: 8/10/12-bit (1080P60Hz, 4K30Hz, 4K60Hz YCbCr 4:2:2/4:2:0) 8-bit (4K60Hz 4:4:4 )
    • HDR, HDR10+, Dolby Vision and HLG function supported
    • Operation Temperature: 32 - 104°F / 0 - 40°C
    • Storage temperature: -4 - 140°F / -20 - 60°C
    • ESD Protection - Human body model: ±8kV (air-gap discharge) & ±4kV (contact discharge)
    • Relative Humidity: 20 - 90% RH (no condensation)
    • Video Bandwidth: 18Gbps
    • Dimentions: 165mm [W] x 88mm [D] x 18mm [H]
    • Weight: Transmitter: 170g, Receiver: 165g
    • Power Supply - Input: AC 100 - 240V 50/60Hz, Output: DC 24V/1A (Locking connector)
    • Power Consumption: 13W
    • Housing: Metal
    • Color: Black
