Delivering resolutions up to 4K@30Hz (YUV 4:4:4), this HDMI extender ensures sharp, vibrant visuals for professional AV environments. Whether using CAT6 or CAT5e, it supports long-distance transmission—up to 230ft (1080p) or 131ft (4K)—without signal loss, making it ideal for control rooms, classrooms, and digital signage applications.
Local Monitoring and Cascade Support with Loop-Out
The built-in HDMI loop-out allows you to connect a local display at the transmitter while also enabling signal cascading to additional extenders. Perfect for large-scale installations, this arc HDMI extender combines seamless video distribution and local previewing in a single, compact solution.
Simplified Setup with One-Way PoC and IR Control
Reduce clutter with Power over Cable (PoC), which allows the receiver to draw power from the transmitter through the same CAT cable. One-way IR pass-through lets users control the source device from the remote display location. Together, these features streamline your HDMI ARC extender setup—no need for extra power sources or complex wiring.
EDID Management and Audio Pass-Through for Seamless Performance
Advanced EDID copy from the receiver or loop-out display ensures optimal compatibility and video output. Supporting premium audio formats like PCM 7.1, Dolby TrueHD, and DTS-HD, this ARC extender delivers both stunning visuals and immersive sound. It’s a reliable arc over Cat6 solution that adapts smoothly to modern and legacy AV systems.
Setup
Compatibility
Dimensions
Includes
OREI 4K HDMI Extender with HDMI Loop Output, Uni- directional IR & Power over Cable (EX-230C)
Key Features:
HDMI 1.4, HDCP 1.4 & DVI 1.0 Compliant – Compatible with legacy and modern devices, ensuring broad system integration and secure content transmission.
Supports Up to 4K@30Hz (YUV 4:4:4) – Delivers crisp, high-resolution video for demanding AV applications.
Long-Distance Transmission over CAT6/5e – • CAT6: Up to 230ft (70m) for 1080p, 131ft (40m) for 4K@30Hz • CAT5e: Up to 197ft (60m) for 1080p, 115ft (35m) for 4K@30Hz
HDMI Loop-Out with Cascading Support – Enables local monitoring and the ability to cascade to additional extenders for larger installations.
EDID Copying from Receiver or Loop-Out Display – Facilitates compatibility and optimized display settings by duplicating EDID from the connected screens.
One-Way Power over Cable (PoC) – Powers the receiver unit directly from the transmitter using a single CAT cable, reducing power supply clutter.
One-Way IR Signal Transmission – Allows remote control of the source device from the display location.
Compact Plug-and-Play Design – Streamlined housing and hassle-free setup make it ideal for professional or home AV installations.
This HDMI Extender with Loop-Out is a reliable solution for extending uncompressed high-definition video, audio, and IR signals over a single CAT5e/6 cable. It supports transmission distances of up to 230 feet (70 meters) at 1080p and 131 feet (40 meters) at 4K@30Hz when using CAT6. Designed to meet HDMI 1.4, HDCP 1.4, and DVI 1.0 standards, it ensures compatibility across a wide range of source and display devices. The built-in HDMI loop-out allows local display and cascading to additional extenders for expanded installations. The EDID copy function enables seamless communication between devices, optimizing video output settings. Audio formats such as PCM 7.1, Dolby True HD, and DTS-HD are supported for a premium multimedia experience. One-way PoC simplifies power requirements, and IR pass-through allows remote control of source equipment. Ideal for classrooms, conference rooms, signage, and control centers, this extender offers dependable performance in a compact and installer-friendly form factor.
CONNECTIVITY
Transmitter:
INPUT:
1 × HDMI [Type A, 19-pin female]
OUTPUT:
1 × HDMI [Type A, 19-pin female]
1 × CAT [RJ45, 8-pin female]
CONTROL:
1 × IR OUT [3.5mm Stereo Mini-jack]
Receiver:
INPUT:
1 × CAT [RJ45, 8-pin female]
OUTPUT:
1 × HDMI [Type A , 19-pin female]
CONTROL:
1 × IR IN [3.5mm Stereo Mini-jack]
PACKAGE CONTENTS
1x Transmitter
1x Receiver
1x IR Blaster Cable
1x IR Receiver Cable
1x Power Adapter
User Manual
SUPPORTED CAT CABLES
CAT5e, CAT6, CAT7:
We recommend you use shielded CAT6 cables & High-Quality HDMI Cables for optimum performance
Yes, you can purchase these things directly from us. Please contact us & we will assist you further.
No, this product doesn not extend multiple screens. It will duplicate the input sources to multple outputs.
Yes, you will be able to get a signal beyond the mentioned distance but the quality of the video decreases with increase in the distance and that too when using with shielded CAT6 cable.
Yes, you can implement the daisy chain method.
Both the ends of the CAT cable should be termed as EIA-568B & the cable should be straight & not crossed.
We recommend you to use High-Quality HDMI cables & shielded CAT6 cables.
Yes, you can purchase the additional transmitter from us. Please contact us & we will let you know the price.
Yes, you can purchase the additional receiver from us. Please contact us & we will let you know the price.
No, this product doesn't upscale/downscale the video resolutions.
You can extend the display devices up to 400 Feet when using with a shielded CAT6 cable.
The issue might be with the CAT cable. This might be due to the external interference of the signals & CAT5e has low bandwidth as compared to the CAT6. We recommend you using shielded CAT6 cable.
If the power and link led lights does not illuminate on the RJ45 port of the transmitter and the receiver, then the transmitter & receiver might be dead.
Please contact us so that we can troubleshoot the issue.
You can upgrade the firmware by connecting the PC & this device via RS-232 cable.
Please note that this product only supports the CEC function between HDMI input & HDMI output 1.
No, optical output doesn't supports CEC due to its limitations. CEC will work only with HDMI devices.
HDBaseT is the technology used for long distance transmission of lossless signals, resulting extremely low latency & giving the best picture quality.
In normal extenders, if you extend your signals up to some extend, the quality of the signals will degrade & you may find some latency issues. HDBaseT is the lastest standard which provides extending your signals to the longer distance without degrading the quality of the signals & with 0 latency.
We recommend you using a shielded CAT6 cables for optimum performance.
Our all the extenders supports IR Frequency & the devices using RF frequency will not be compatible with our products.
The IR Blaster/Emitter should be connected to the IR out port on the Transmitter and the IR Receiver should be connected to the IR in on the Receiver.
