4K 4x4 HDMI Matrix Switch - Supports UltraHD 4K@60Hz 4:4:4, HDR10, RS-232 (UHD-404R)


$149.99
Shipping calculated at checkout.
SKU: UHD-404R

    • 4 Inputs - 4 output HDMI Matrix switch
    • Video resolution up to 4K@60Hz 4:4:4 - EDID Control
    • Supports HDR10 and RS-232 control
    • Any two of the four HDMI outputs support Auto-Downscaling

Overnight shipping*:
Two days shipping:

*Overnight shipping doesn't include Weekends, or any holidays.

Minus Plus
Reseller & Installer Discounts
Add to Wishlist
30 Days Return
30 Days Return
1 Year Warranty
1 Year Warranty
No-Contact Delivery
Free shipping in USA
More Details Right

OREI UHD-404R: 4x4 HDMI Matrix Switch

Key Features:
  • 4x4 HDMI Matrix Switch 4-Input ports: 4 HDMI (female type), 4-Output ports: 4 HDMI (female type)
  • Ability to display the same or 4 different screens on all 4 displays.
  • This is HDCP 2.2 and HDMI 2.0 compliant
  • 18Gbps transmission rate up to 600MHz Bandwidth
  • Video Resolution up to 4K@60Hz 4:4:4 and HDR10 passthrough
  • Supports full 3D/2D, Ultra HD resolutions up to 4K @ 60Hz, and HD resolutions up to 1080p
  • 4 In 4 Out HDMI Matrix Switch - EDID management with 16 Built-In EDID States
  • Audio output: LPCM7.1/DTS-HD/DTS-Audio/Dolby Digital Plus/Dolby TrueHD 7.1/Dolby Digital 7.1/Dolby Atmos
  • Any two of the four HDMI outputs support Auto-Downscaling
  • Flexible control via buttons on the front of the device, IR remote control, and RS-232
  • Lightning Protection, Surge Protection, ESD Protection

Few sample applications:

The OREI UHD-404R switcher is perfect for splitting and switching your HDMI signal to 4 different displays. The OREI UHD-404R matrix has four HDMI inputs and four HDMI outputs, so you can switch between four input source devices and send the signal simultaneously to four displays. No setup or special configuration is required, simply connect the input device(s) and output device(s) and start using it! The built-in auto-adjusting amplifier ensures no signal loss. The built-in amplifier will then regenerate the HDMI signal before sending it to the outputs. The UHD-404R supports full 3D/2D, Ultra HD resolutions up to 4K @ 60Hz 4:4:4, HD resolutions up to 1080p, Deep Color up to 48 bit, and all audio channels up to 7.1. Note that you don't have to have four inputs and four outputs to use this device. You can use just the switching function if you only have one display or just the splitter function if you have only one input. Convenient control via buttons on the front of the device, IR remote control, and RS-232. Any two of the four HDMI outputs support Auto-Downscaling. Extensive EDID management with 16 built-in EDID states.
