1x2 HDMI Splitter W/ Audio Out: 1-in 2-out, UltraHD 8K, EDID (BK-102A)
- Split 1 HDMI Source to 2 identical displays
- Extract Audio through Optical / Analog
- Video resolution upto 4K@120Hz
- Compliance: HDMI 2.1 - HDCP 2.3
OREI BK-102A: 1x2 8K HDMI Splitter with Audio Out
- WILL NOT WORK TO EXTRACT AUDIO
- NOT COMPATIBLE WITH CAPTURE CARD
- DOES NOT SUPPORT ARC
- Split two HDMI 2.1 input signal to two HDMI output signals identical to the input signal (Both output will have to support 8K)
- 8K 40 Gbps Powered HDMI Splitter
- Input: 1x HDMI & Outputs: 2x HDMI 1x Optical 1x L/R Analog
- EDID management
- Built-in Equalizer, Retiming and Driver
- 1 in 2 out HDMI Splitter
- Supported resolution: up to 8K, 4K/120Hz, 1080p, 720p, HDR, HDR10, HDR10+
- Supported Audio: LPCM, Dolby-AC3, DTS7.1, DSD/Dolby TrueHD/DTS-HD master audio, Essentially all available audio options are supported
- Supports HDR, HDR10, HDR10+, Dolby Vision, HLG Pass Through
- Supports HDMI Audio Formats: LPCM, Dolby Digital / Plus/EX, Dolby True HD, DTS, DTS-EX, DTS-96/24, DTS High Res, DTS-HD Master Audio, DSD.
- Heavy-duty cool metal enclosure protects the insides and keeps the unit cool by aiding in quick heat absorption and dissipation
- Output the same resolution on both TVs.
- Compact in size
- Easy plug & play installation
- HDCP 2.3 Compliant
- Includes 100-240 50/60 Hz auto switching power supply for use anywhere in the world
- Lifetime OREI Tech Support & 12-Month Manufacturer's Warranty
The OREI BK-102A is a reliable distribution amplifier powered splitter that will take HDMI 2.1 signal up to 8K and duplicate the signal to up to 2 HDMI displays simultaneously, creating an impressive lossless image or audio transmission via HDMI cable. With this splitter your also able to extract the Audio through Optical & Analog.
Compact, durable and easy to set up and operate. Ideal for trade show, conference room, lecture halls, bed room, living room, kitchen room and backyard.
Please note that this hdmi 2.1 splitter will duplicate the source to the two output displays. It can’t be used to extend a desktop for PC or a laptop. If the connected displays do not support the same resolution then the splitter will lower the output resolution to the next best resolution supported by both displays and same goes with the audio signal. We recommend using this HDMI 2.1 splitter with high quality HDMI cables 30 feet or less.
The package includes Orei BK-102A HDMI splitter 8K, 5V AC Adapter & user manual.
