4K@60hz HDMI™ Extender (Loop, Bi-IR, SPDIF) - 230ft (cat6)-UHD-EX230A-K
- Loop output
- Video resolutions up to 4K@60Hz and 2K@60Hz
- ARC support
*Overnight shipping doesn't include Weekends, or any holidays.
Couldn't load pickup availability
1. Uncompressed 4K HDMI Extension with Full AV Support
The UHD-EX230A-K delivers flawless 4K@60Hz video transmission up to 230 feet (70 meters) over a single Cat6/7 cable. With HDMI 2.0b and HDCP 2.2 compliance, it ensures smooth compatibility with the latest 4K content sources and display devices. This 4K HDMI extender offers the performance needed for high-end AV setups in both home and commercial environments.
2. Immersive Video and Audio Experience
Enjoy lifelike visuals with full support for HDR10+ and Dolby Vision formats. The 18Gbps video bandwidth guarantees high-quality, uncompressed signal delivery. Whether you’re running a digital signage system or a home theater, this HDMI over Cat 6 cable extender preserves every detail of your video and audio streams with precision.
3. Integrated ARC Functionality and Optical Audio Extraction
Designed for audio flexibility, this HDMI ARC extractor allows audio to be pulled from either the source or an ARC-enabled TV and output via a dedicated optical port. Supporting formats like LPCM 8.1CH, Dolby TrueHD, and DTS-HD Master Audio, it enables clean audio routing to external systems, enhancing your HDMI via Ethernet installation.
4. Local Display, Remote Control, and Simplified Power
With HDMI loop-out on the transmitter, you can monitor the signal locally while transmitting it to a remote display. Bi-directional IR control allows you to operate the source or display from either location. The entire system runs with a single power adapter thanks to Power over Cable (PoC), making this Cat6 extender both efficient and easy to install.
OREI UHD-EX230A-K: 4K HDMI Extender Over Ethernet CAT6/7 - With ARC Audio Extraction through Optical - Up to 230 feet
-
HDMI 2.0b & HDCP 2.2 Compliant – Delivers compatibility with modern AV equipment and content protection standards.
-
Supports Resolutions up to 4K@60Hz – Transmits 4K and 2K video up to 230 ft (70 m) over Cat6/7 cable.
-
18Gbps Video Bandwidth – Ensures high-performance, uncompressed audio and video signal transmission.
-
HDR10+ & Dolby Vision Support – Maintains full compatibility with high dynamic range video formats.
-
Audio Extraction via Optical Output – Extracts audio from either the HDMI source or ARC-enabled TV.
-
Multi-Format Audio Pass-through – Supports LPCM 8.1CH, Dolby TrueHD, and DTS-HD Master Audio.
-
HDMI Loop Output – Allows local display connection at the transmitter side.
-
Bi-directional IR Control – Enables remote operation of source or display from either end.
-
Power over Cable (PoC) – Requires only one power adapter for the entire extender kit.
-
Compact & Durable Design – Simplifies installation in both commercial and residential environments.
UHD-EX230A-K is a high-performance HDMI extender with integrated audio extraction, engineered to deliver uncompressed AV signal transmission over extended distances. It supports 4K@60Hz and 2K@60Hz video up to 230 feet (70 meters) via a single Cat6/7 cable and is fully compliant with HDMI 2.0b and HDCP 2.2 standards.
With a robust 18Gbps bandwidth, it ensures flawless video quality and supports premium formats including HDR10+ and Dolby Vision.
This extender features ARC (Audio Return Channel) capability and allows audio extraction either from the HDMI source or an ARC-enabled TV, with output through an optical port. It supports audio pass-through for formats such as LPCM 8.1CH, Dolby TrueHD, and DTS-HD Master Audio.
Additional highlights include HDMI loop output on the transmitter for local display connectivity, bi-directional IR for full remote control flexibility, and Power over Cable (PoC) technology—requiring only a single power adapter for the entire system. Its durable, compact design makes it a versatile choice for commercial AV setups and high-end residential installations.
UHD-EX230A-K User Manual Download
UHD-EX230A-K Specifications Sheet
