4K@30hz HDMIā¢ Extender (Loop, IR) - 130ft (cat6)-EX-165C+
- HDR pass-through
- Video resolutions up to 1080p@60Hz
- Power over Cable technology
*Overnight shipping doesn't include Weekends, or any holidays.
Couldn't load pickup availability
1. Extend HDMI Signals in 4K with Zero Latency
This HDMI signal extender supports resolutions up to 4K@30Hz (4:4:4), ensuring crystal-clear visuals and vibrant color accuracy. With support for HDMI 1.4, HDCP 1.4, and DVI 1.0, it's compatible with a wide range of source and display devicesāmaking it an ideal HDMI extender 4K solution for classrooms, home theaters, and digital signage setups.
2. Long-Distance Transmission Over CAT5e/6 Cables
Transmit uncompressed audio and video up to 230ft (1080p) or 131ft (4K30) using a single CAT6 cable. Even with CAT5e, the extender cat6 performance remains robust, reaching 197ft (1080p). This 4K HDMI extender over CAT6 allows for high-quality HDMI over Ethernet 4K transmission in professional AV environments and larger room installations.
3. Local HDMI Loop-Out and Cascading Support
The integrated HDMI loop-out enables real-time local monitoring, while cascading support allows signal distribution to multiple displays across greater distances. Whether you're building a signage wall or extending video across conference rooms, this extender HDMI 4K device offers flexibility and scalability with consistent signal integrity.
4. Smart Features for Simplified Installation
Featuring one-way Power over Cable (PoC), the system requires power only at the transmitterāreducing cable clutter and simplifying setup. EDID copy ensures optimal display compatibility, while the one-way IR control allows users to manage source devices from the remote display side. Its compact design is perfect for clean, discreet installations in any HDMI cat 5 extender or cat6-based system.
OREI EX-165C+: HDMI Extender over Ethernet (70m) with One way IR & PoC
- HDMI 1.4, HDCP 1.4 and DVI 1.0 compliant
- Ā Support video resolution up to 4k2k@30Hz YUV 4:4:4
- The maximum transmission distance via a single CAT6/5EĀ cable is as follows:
Ā CAT6: 230ft/70m for 1080p, 131ft/40m for 4K30
Ā CAT5E: 197ft/60m for 1080p, 115ft/35m for 4K30 - Support copying EDID from receiver display or loop out display
- Allow for cascading via additional HDMI loop out port
- Support one-way POC functionality (from transmitter to receiver)
- One-way IR signal transmission
- Compact design for easy and flexible installationĀ
This HDMI Extender can extend high definition video/audio signalĀ and IR control signal up to 230ft/70m for 1080p resolution, andĀ 131ft/40m for 4K30 resolution via a single CAT6 cable, which canĀ achieve zero-delay, uncompressed long-distance transmission
between the transmitter and receiver. This extender with HDMI loopĀ output can be cascaded to the next extender, supporting resolutionĀ up to 4K@30Hz. It supports EDID copy function (you can chooseĀ local or remote EDID). It supports audio formats up to PCM7.1,Ā Dolby True HD, DTS HD. This product can be widely used in multimedia conference halls, TV teaching and large-screen displays.
EX-165C+ User Manual Download
EX-165C+ Specifications Sheet
