ToVi X4 4K Wall Plate Encoder (Video Wall, KVM) - X4UH-WUC-ETX

ToVi X4 Series (4K) w/ KVM

•  HDCP 2.2 & DP 1.2 Compliant – Ensures compatibility with modern content protection and DisplayPort standards.
• Ultra HD Video Support – Transmits video resolutions up to 4K@60Hz 4:4:4, compliant with HDMI™ 2.0b specifications.
• 18Gbps Video Bandwidth – Delivers uncompressed, high-quality video signals.
• Long-Distance Transmission – Extends signals up to 328ft (100m) over Cat6/6A/7 cables.
• HDMI™ & USB-C Dual Inputs – Supports automatic or manual source switching for flexible operation.
• USB-C Data & Charging – The USB-C 1 port enables video, audio, USB data transfer, and device charging via adapter on USB-C 2 port.
• Full Signal Transmission Over IP – Transmits video, analog audio, RS232, CEC, and USB signals over Ethernet.
• KVM & USB 2.0 Support – Ideal for interactive and control applications, with camera and peripheral support.
• Audio Embedding & De-embedding – Flexible audio routing for AV system integration.
• Intelligent Video Wall Support – Supports point-to-point, video matrix, and video wall configurations up to 9x9.
• MJPEG Sub stream – Allows real-time video preview via portable devices or control apps.
• Comprehensive Control Options – Web GUI, RS-232, TCP/IP, Telnet, SSH, and third-party system support
• HDR & Dolby Vision Pass-through – Ensures compatibility with high dynamic range content including HDR10, Dolby Vision, and HLG.
• Premium Audio Formats – Supports LPCM 2.0/5.1/7.1CH, Dolby Digital, Dolby Atmos, DTS:X, and more.
• Power over Ethernet (PoE) – Simplifies installation with standard 802.3at PoE or local 12V power option.
• US 2-Gang Wall-plate Design – Compact, professional form factor for discreet in-wall installations.
• Smart Networking Design – Optimized for use with 1G Ethernet switches, routers, and hubs for flexible system deployment


X4UH-WUC-ETX is a high-performance AV over IP Encoder designed for professional AV distribution over a Gigabit network. Built on advanced JPEG2000 technology with ASPEED AST1530 for image compression, it ensures visually lossless 4K@60Hz 4:4:4 video transmission with ultra-low latency, ideal for KVM and interactive applications. This wall-plate encoder features dual HDMI™ and USB-C inputs, supporting automatic and manual switching between sources, along with audio embedding and de-embedding, USB 2.0/KVM functionality, bi-directional RS-232 and CEC pass-through. With support for advanced video formats like HDR10, Dolby Vision, and HLG, and comprehensive audio compatibility including Dolby Atmos, DTS:X, and LPCM up to 7.1CH, the X4UH-WUC-ETX is a reliable solution for demanding AV installations in conference rooms, educational facilities, and control centers. The system is Linux-based for enhanced stability and offers flexible control via Web GUI, RS-232, TCP/IP, and third-party control systems. Its smart networking design, PoE support, and compact 2-gang wall-plate form factor make it easy to install and manage.
